BELDEN  19105 - Home & High-End Audio Power Cable

Color Code: 010 (Black)

Length: 250ft, 75M

Application

Home & High-End Audio Power Cable, 홈, 하이엔드 오디오 전원용 케이블

Physical Characteristics (Overall)

Conductor: 3C x 10(105x30)AWG, BC - Bare Copper

Insulation: EPDM - Ethylene Propylene Diene Monomer

Color Chart: 1) Black / 2) White / 3) Green

Shield: No

Jacket: SBR - Styrene Butadiene Rubber

Standards

NEC/(UL) Specification: S

CSA AWM Specification: S

Flammability

CSA Flammability: FT2

UL voltage rating: 600 V RMS

_유전체 내전압: 3000 V AC Applied For 1 Min.
